| - | Part Number | F (Thread) | Ø | L | S1 | S2 |
|---|---|---|---|---|---|---|
| - | - | UNF | inch | mm | mm | mm |
| -01 | DP1JCFF-0404 | 7/16"-20 | 6.00 | 49.00 | 9/16" | 9/16" |
| -05 | DP1JCFF-0505 | 1/2"-20 | 8.00 | 53.00 | 11/16" | 5/8" |
| -06 | DP1JCFF-0604 | 9/16"-18 | 6.00 | 52.00 | 9/16" | 11/16" |
| -06 | DP1JCFF-0606 | 9/16"-18 | 10.00 | 58.00 | 11/16" | 11/16" |
| -08 | DP1JCFF-0806 | 3/4"-16 | 10.00 | 63.00 | 11/16" | 7/8" |
| -08 | DP1JCFF-0808 | 3/4"-16 | 12.00 | 67.00 | 13/16" | 7/8" |
| -10 | DP1JCFF-1008 | 7/8"-14 | 12.00 | 72.00 | 7/8" | 1" |
| -10 | DP1JCFF-1010 | 7/8"-14 | 16.00 | 74.00 | 15/16" | 1" |
| -12 | DP1JCFF-1210 | 1-1/16"-12 | 16.00 | 79.00 | 1-1/16" | 1-1/4" |
| -12 | DP1JCFF-1212 | 1-1/16"-12 | 20.00 | 81.00 | 1-1/16" | 1-1/4" |
| -16 | DP1JCFF-1612 | 1-5/16"-12 | 20.00 | 84.00 | 1-1/4" | 1-1/2" |
| -16 | DP1JCFF-1616 | 1-5/16"-12 | 25.00 | 98.60 | 1-3/8" | 1-1/2" |
| -16 | DP1JCFF-1620 | 1-5/16"-12 | 32.00 | 100.00 | 1-3/8" | 2" |
| -20 | DP1JCFF-2020 | 1-5/8"-12 | 32.00 | 100.00 | 1-7/8" | 2" |
| -20 | DP1JCFF-2024 | 1-5/8"-12 | 40.00 | 100.00 | 1-7/8" | 2-1/4" |
| -24 | DP1JCFF-2424 | 1-7/8"-12 | 40.00 | 98.00 | 2-1/8" | 2-1/4" |
| -32 | DP1JCFF-3232 | 2-1/2"-12 | 50.00 | 120.00 | 2-1/2" | 2-7/8" |
