DPF2T No-Skive Ferrule for SAE100 R1AT/R2AT or EN853 1SN/2SN

  • DCompanyDME
  • PProduct RangeHose Fitting
  • FHose Fitting TypeFerrule
  • 2TAvailable Hose TypeSAE100 R1AT/R2AT or EN853 1SN/2SN
  • DME&JDE Code: DPF2T
  • Product Type: Hose Fitting
  • Hose Fitting Type: Ferrule
  • Available Hose Type: SAE100 R1AT/R2AT or EN853 1SN/2SN
Technical Data of DPF2T
  • -03
  • -04
  • -05
  • -06
  • -08
  • -10
  • -12
  • -16
  • -20
  • -24
  • -32
A drawing of DPF2T no-skive ferrule.
Technical Data of DPF2T
- PART NUMBER Ø A D L
- - Inch mm mm mm
-01 DPF2T-03 3/16" 3.35 21.00 23.00
-04 DPF2T-04 1/4" 3.55 23.00 30.50
-05 DPF2T-05 5/16" 3.35 24.00 30.00
-06 DPF2T-06 3/8" 3.20 26.00 32.00
-08 DPF2T-08 1/2" 3.00 29.00 34.00
-10 DPF2T-10 5/8" 3.35 33.00 37.00
-12 DPF2T-12 3/4" 3.25 37.00 42.00
-16 DPF2T-16 1" 4.05 47.00 51.00
-20 DPF2T-20 1-1/4" 4.60 59.00 59.00
-24 DPF2T-24 1-1/2" 5.50 67.00 67.00
-32 DPF2T-32 2" 5.75 80.00 72.00
