DPF2T-OP No-Skive One Piece Ferrule for SAE100 R1AT /2AT or EN853 1SN/2SN ,EN857 2SC/1SC

  • DCompanyDME
  • PProduct RangeHose Fitting
  • FHose Fitting TypeFerrule
  • 2TAvailable Hose TypeSAE100 R2AT or EN853 2SN/EN857 2SC
  • DME&JDE Code: DPF2T-OP
  • Product Type: Hose Fitting
  • Hose Fitting Type: Ferrule
  • Available Hose Type: SAE100 R2AT or EN853 2SN/EN857 2SC
Technical Data of DPF2T-OP
  • -04
  • -05
  • -06
  • -08
  • -10
  • -12
  • -16
  • -20
  • -24
  • -32
A drawing of DPF2T-OP no-skive ferrule.
Technical Data of DPF2T-OP
- PART NUMBER Ø A D1 D2 L
- - Inch mm mm mm mm
-01 DPF2T-OP-04 1/4" 18.70 11.10 15.81 28.00
-05 DPF2T-OP-05 5/16" 19.90 12.30 17.70 27.00
-06 DPF2T-OP-06 3/8" 22.70 14.30 20.22 31.00
-08 DPF2T-OP-08 1/2" 25.90 18.00 23.66 33.00
-10 DPF2T-OP-10 5/8" 29.60 21.40 26.80 36.00
-12 DPF2T-OP-12 3/4" 32.90 24.30 30.45 39.60
-16 DPF2T-OP-16 1" 40.90 30.30 39.50 50.00
-20 DPF2T-OP-20 1-1/4" 49.80 37.80 50.00 56.80
-24 DPF2T-OP-24 1-1/2" 57.50 44.00 56.00 70.00
-32 DPF2T-OP-32 2" 71.00 57.00 69.50 72.50
