Italy Technology Equipment
New-Standard
Oil resistance synthetic rubber (CSM)
Synthetic rubber with excellent aging resistance and weather ability (CPE/CSM)
110 Bar / 1620 PSI
| Part Number | Hose Size | I.D. | O.D. | Operating Pressure | Burst Pressure | Weight | Length Per PCS | Ferrule | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| I.D. | Dash Size | mm | inch | mm | mm | bar | psi | bar | psi | kgs/m | meter | DME Code |
| JDE821106-6 | -04 | 6 | 1/4" | 6.3±0.2 | 14.5±0.3 | 162-212 | 2350-3074 | 650-850 | 9400-12300 | 0.28 | 45-55 | 821106-6 |
| JDE821106-8 | -05 | 8 | 5/16" | 8±0.2 | 18±0.4 | 162-212 | 2350-3074 | 650-850 | 9400-12300 | 0.31 | 45-55 | 821106-8 |
| JDE821106-9.5 | -06 | 9.5 | 3/8" | 9.5±0.3 | 18.5±0.4 | 162-212 | 2350-3074 | 650-850 | 9400-12300 | 0.31 | 45-55 | 821106-9.5 |
| JDE821106-9.5 | -06 | 9.5 | 3/8" | 9.5±0.3 | 20±0.4 | 162-212 | 2350-3074 | 650-850 | 9400-12300 | 0.32 | 45-55 | 821106-9.5 |
| JDE821106-9.8 | -07 | 9.8 | 13/32" | 9.8±0.3 | 18.5±0.4 | 162-212 | 2350-3074 | 650-850 | 9400-12300 | 0.30 | 45-55 | 821106-9.8 |
| JDE821106-9.8 | -07 | 9.8 | 13/32" | 9.8±0.3 | 19.8±0.4 | 162-212 | 2350-3074 | 650-850 | 9400-12300 | 0.31 | 45-55 | 821106-9.8 |
| JDE821106-10 | -07 | 10 | 13/32" | 10±0.3 | 20±0.5 | 162-212 | 2350-3074 | 650-850 | 9400-12300 | 0.32 | 45-55 | 821106-10 |
| JDE821106-13 | -08 | 13 | 1/2" | 13±0.5 | 23±0.5 | 162-212 | 2350-3074 | 650-850 | 9400-12300 | 0.34 | 45-55 | 821106-13 |
Cover Type: Smooth
Packing Type: Roll, Pallet
Outward Appearance: Black
